Electrical fuel pump test bench , test equipment 50 / 60HZ 0 - 16bar

Electrical fuel pump test bench , test equipment 50 / 60HZ 0 - 16bar

Electrical fuel pump test bench , test equipment 50 / 60HZ 0 - 16bar

Product Details:

Place of Origin: CHINA
Brand Name: ADMTECK
Certification: CE
Model Number: 12PSDW-A

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: PALLET
Delivery Time: TWO WEEKS
Payment Terms: 30% T/T in advance, 70% T/T before shipment L/C Western Union
Supply Ability: 50SETS
Contact Now
Detailed Product Description
Inner Pressure: 0 - 16bar Color: Green
Power Supply Frequency: 50 / 60HZ Cylinders: 6|12
Power: 5.5kw|7.5kw|11kw|15kw|18.5kw|22kw Rated Voltage: 415V|380V|220V

Electrical fuel pump test bench / diesel injection test equipment 50 / 60HZ 0 - 16bar



Quick Details





Function



1.  Fuel delivered from each cylinder on any speed can be tested

2.  Speed, temperature, counter, pressure, Rack meter can be displayed on the numeric unit of test bench.

3.  Forced oil lubrication function (Optional)

4.  Directly driven by motor, variable frequency stepless speed regulation

5.  Static inspection on the delivery time of each cylinder

6.  Inspection on Performance of the mechanical and pneumatic governor

7.  Inspection on performance of the solenoid valve

8.  Inspection on performance of the minus pressure of pneumatic governor

9.  Inspection on the performance of the Pressure Compensator

10. Oil returned volume of distribute pump

11. Inspection on the Inner pressure of the VE pump

12. Inspection on the performance of the minus pressure of pneumatic governor

13. Inspection on Pump body sealing performance





Competitive Advantage:

  • Reasonable Price
  • Good after Service
  • More Than 10 Years’ Experience
  • NICE APPEARANCE
  • GOOD QUALITY
  • NEW DESIGN
  • Highly advanced diesel injection/injector technology
  • EASY TO MAINTAIN



Description:



Power: 5.5,7.5,11,15,18.5,22kw

Rated Voltage: 415V/380V/220V

Rated Voltage: 50/60HZ

Cylinders: 6 / 12

Speed Range: 0—4000rpm

Temperature Control Range: 30-65℃ ,Accuracy:±2℃

Packaging Detail: wooden box

Pressure meter: Low pressure:0-6bar;

high pressure: 0-60bar;

inner pressure: 0-16bar;

Vacuum pressure: 1-2.5bar;

Oil meter : 0-10bar

Usage: Auto Testing Machine

Color: green blue yellow or on request

Power: Electronic





Function



1.  Fuel delivered from each cylinder on any speed can be tested

2.  Speed, temperature, counter, pressure, Rack meter can be displayed on the numeric unit of test bench.

3.  Forced oil lubrication function (Optional)

4.  Directly driven by motor, variable frequency stepless speed regulation

5.  Static inspection on the delivery time of each cylinder

6.  Inspection on Performance of the mechanical and pneumatic governor

7.  Inspection on performance of the solenoid valve

8.  Inspection on performance of the minus pressure of pneumatic governor

9.  Inspection on the performance of the Pressure Compensator

10. Oil returned volume of distribute pump

11. Inspection on the Inner pressure of the VE pump

12. Inspection on the performance of the minus pressure of pneumatic governor

13. Inspection on Pump body sealing performance





Specifications:



Motor power

5.5,7.5,11,15,18.5,22kw

Power supply voltage

415,380,220v

Power supply frequency

50/60 HZ

Protection level

IP54

Speed range

0-4000 rpm

Counter setting range

0-9999

Temperature setting range

0-80

Center height of driving shaft

125mm

DC power

12/24V

Diameter of the Driving connector

120mm

Measuring tube

45ml,150ml,260ml(optional)

Number of Measuring cylinder

6,8,12

Oil Supply pump

10L/min

Oil supply pressure: High pressure

0-40bar

Oil supply pressure: low pressure

0-4bar

Oil tank cubage

60L

Heat Power

2kw

Temperature controlled range

30-65

Size

2100*1060*1750mm

Weight

950kg







Competitive Advantage:



Advantages with ranges of adjustment speed, stable speed, large torque, easy operation and so on.
