| Place of Origin: | CHINA |
| Brand Name: | ADMTECK |
| Model Number: | ADM9200 |
| Certifiion: | CE |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Polyboard |
| Delivery Time: | TWO WEEKS |
| Payment Terms: | 30% T/T in advance, 70% T/T before shipment or L/C or Western Union |
| Supply Ability: | 50SETS |
| Color: | Blue/green | Cooling Method: | Fan Cooling |
|---|---|---|---|
| Fuel Tank Capacity: | 20L | Product Name: | Common Rail Injector Test Bench |
| Usage: | Auto Testing Machine | Motor Power: | 4Kw |
| High Light: | common rail diesel injector test bench,fuel injection pump test bench |
||
ADMTECK
ADM9200, Common Rail Injector Test Bench, for testing different common rail injectors, 4Kw,2000Bar, measuring with sensors
Quick Details
Competitive Advantage:
Power: Electronic
Usage: Auto Testing Machine
Color: blue yellow or on request
Cooling method: Water Cooling or Fan Cooling
Temperature range: 30—50℃
For testing and calibrating:
Main technical specifiions:
1. Motor power: 4Kw；
2. Variable frequency motor speed range: 1000rpm；
3. Pressure control range: 10—2000bar；
4. Pressure control accuracy: ±3bar；
5. Injection frequency setting range:
100—1000 Times/min；
6. Metering range : 20ml
7. Fuel tank capacity: 20L；
8. Filter accuracy: 5µm；
9. Temperature range: 30—50℃
Main functions:
1. Test common rail injectors of BOSCH,DELPHI,DENSO
2. Check the sealing of CR injectors
3. Check the backflow and the injection volume under full-loaded status
4. Test the injection volume at the emission point
5. Test the flow volume of idling status
6. Test the pre-injected volume of the CR injectors
7. Clean the injectors while testing
8. Testing data could be saved and printed
9. Standard parameters settable
Technical Specifiion:
|
1. Power |
4KW |
|
2. Variable frequency motor speed range |
1000rpm |
|
3. Pressure control range |
10—2000bar |
|
4. Pressure control accuracy |
±3bar |
|
5. Injection frequency setting range |
100—1000 Times/min |
|
6. Metering range |
20ml |
|
7. Fuel tank capacity |
20L |
|
8. Filter accuracy |
5µm |
|
9. Temperature range |
30—50℃ |
Factory Pictures:
