| Place of Origin: | CHINA |
| Brand Name: | ADMTECK |
| Model Number: | ADM8719 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PALLET |
| Delivery Time: | TWO WEEKS |
| Payment Terms: | 30% T/T in advance, 70% T/T before shipment L/C Western Union |
| Supply Ability: | 50SETS |
| Cylinders: | 6 / 12 | Rated Voltage: | 0-4000rpm. |
|---|---|---|---|
| Product Name: | Common Rail Test Equipment | Power: | 18.5Kw |
| Test Injector Brand: | BOSCH / DELPHI / DENSO | Working Voltage: | 220V / 380V / 415V |
| High Light: | common rail diesel test equipment,common rail injector test bench |
||
18.5Kw Cooling capacity BOSCH common rail test equipment / bench
Quick Details
Power: 15Kw,18.5Kw etc.
Rated Voltage: 220V/380V/415V
Rated Voltage: 50/60HZ
Cylinders: 6 / 12
Speed Range: 0—4000rpm
Temperature Control Range: 42℃ ,Accuracy:±2℃
Fuel supply pressure range: 0-0.4Mpa
Feed Volume Measurement Range: 0.03----45L/H
Return Volume Measurement Range: 6---400L/H
Max pressure: 2000 bar
Color: green blue yellow or on request
Weight: 1080kgs
Usage: Auto Testing Machine
Power: Electronic
For testing and calibrating:
1. Mechanical in-line pumps and distributor pumps
2. Electronic control VE pumps and in-line pumps high pressure common rail pumps: BOSCH CP1, CP2,
CP3, DELPHI, SIMENS, DENSO HP0, HP2, HP3 PUMP
3. Common rail injectors
4. The testing database could be updated
5. Check and calibrate automatically and give out the testing report
6. With industrial computer, more stable and reliable
Technical Specifiion:
|
1. Power |
11Kw,15Kw,18.5Kw,22Kw etc |
|
2. Rated Voltage |
220V/380V/415V |
|
3. Rated Voltage |
50/60HZ |
|
4. Cylinders |
6 / 12 |
|
5. Speed Range |
0—4000rpm |
|
6. Temperature Control Range |
42℃ ,Accuracy:±2℃ |
|
7. Backflow pressure control range |
0—3 bar |
|
8. Feed Volume Measurement Range |
0----45L/H |
|
9. Return Volume Measurement Range |
0---400L/H |
|
10. Max pressure |
2000 bar |
Competitive Advantage:
Factory Pictures
