Name: CRB-E3000 Common Rail Pump Test Bench with 2500 Bar Max Pressure, 0-4000 rpm Speed Range, and 70% Energy Feedback Efficiency
Brand: WUXI ADM TECHNOLOGY DEVELOPMENT CO.,LTD
SKU: CRB-E3000
Price: 16,500.00 USD
Availability: InStock

Home Products Common Rail Pump Test Bench

CRB-E3000 Common Rail Pump Test Bench with 2500 Bar Max Pressure, 0-4000 rpm Speed Range, and 70% Energy Feedback Efficiency

Product Details:

Place of Origin:	Shandong, China
Brand Name:	CRB-E3000
Certification:	ISO 9001:2015
Model Number:	CRB-E3000

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 8000-25000 / Set
Packaging Details:	Export-grade fumigated plywood crate with EPE foam cushioning, waterproof PE cover, and shock indicators
Delivery Time:	20-35 working days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	50 Sets per Month

Contact Now

Detailed Product Description

Max Test Pressure:	2500 Bar	Motor Power:	15 KW
Speed Range:	0-4000 Rpm	Energy Feedback Efficiency:	Up To 70% Recovery
Torque Range:	0-150 Nm	Control System:	PLC With Energy Management Software
Cooling Method:	Intelligent Variable-Speed Fan Cooling	Fuel Supply:	12V / 24V DC
Compatible Pump Series:	CR920, CR940, CR950, CP3, CP4	Annual Energy Savings (Est.):	Up To 15,000 KWh
Power Factor:	≥0.95	Power Supply:	AC 380V 50Hz 3-Phase
Highlight:	Wide Speed Torque Range , Energy Feedback System , 2500 Bar Pump Testing

CRB-E3000 Wide Speed Range Energy Saving Common Rail Pump Test Bench

The CRB-E3000 sets a new benchmark for operational efficiency in common rail pump testing by integrating a state-of-the-art energy feedback system that recovers and recycles the mechanical energy generated during pump evaluation cycles. Where conventional test benches dissipate the energy consumed during testing as heat through cooling systems, the CRB-E3000 captures this energy through a regenerative drive system and feeds it back into the facility power grid, achieving energy recovery rates of up to 70 percent. This translates to estimated annual electricity savings of over 15,000 kWh per test bench under typical workshop utilization, representing a rapid return on investment through dramatically reduced operational costs.

Key Features

Regenerative Energy Feedback Technology: Integrated IGBT-based regenerative drive captures mechanical energy from the pump during deceleration and load testing phases, converting it to clean electrical power fed back into the workshop power grid.
Verified Energy Cost Reduction: Real-world measurements demonstrate energy savings exceeding 70% compared to traditional resistive-load test benches, with documented annual savings of up to 15,000 kWh per unit.
Extended Speed Range Flexibility: Operating from true zero-speed start through 4000 rpm, covering the complete testing envelope required by modern common rail pumps.
Intelligent Variable-Speed Cooling: Cooling fan speed automatically adjusts based on real-time system temperature monitoring for optimal energy efficiency.
Built-in Energy Analytics Dashboard: PLC control interface includes dedicated energy monitoring screen displaying real-time and cumulative energy consumption, recovery, and cost data.
Environmental Compliance Ready: Supports ISO 14001 environmental management certification, LEED green building credit requirements, and national energy efficiency regulations.

Technical Specifications

Parameter	Specification
Model	CRB-E3000
Max Test Pressure	2500 Bar
Motor Power	15 KW
Speed Range	0-4000 rpm
Torque Range	0-150 Nm
Energy Feedback Efficiency	Up to 70% Recovery
Estimated Annual Savings	15,000 kWh
Control System	PLC with Energy Management Software
Cooling Method	Intelligent Variable-Speed Fan Cooling
Fuel Supply Voltage	12V / 24V DC
Compatible Pump Series	CR920, CR940, CR950, CP3, CP4
Power Factor	≥0.95
Power Supply	AC 380V 50Hz 3-Phase
Net Weight	510 KG
Dimensions (L×W×H)	2000 × 920 × 1680 mm

Applications

The CRB-E3000 is the ideal investment for high-volume common rail pump remanufacturing facilities, diesel injection service networks operating multiple test benches simultaneously, and any organization where electricity costs represent a significant portion of the operational budget. Its rapid return on investment through energy savings makes it particularly attractive for facilities in regions with high industrial electricity rates and for companies pursuing environmental sustainability certifications. The energy feedback technology also reduces the heat load on workshop air conditioning systems, providing secondary energy savings in climate-controlled testing laboratories.

Packaging & Quality Assurance

The CRB-E3000 ships in a reinforced fumigated plywood export crate with integrated shock indicators for logistics monitoring. The regenerative drive unit is transported in a separate internally padded compartment to prevent vibration damage to sensitive power electronics. Each shipment includes a factory energy performance test report documenting the verified energy recovery efficiency, a detailed energy savings projection model tailored to local electricity rates, and comprehensive documentation supporting green procurement and sustainability reporting requirements. Standard delivery time is 25-35 working days.
