PT Injector Test Bench 450 X 450 X 350 1.5Kw 1050 R/Min 3phases

PT Injector Test Bench 450 X 450 X 350 1.5Kw 1050 R/Min 3phases

  • PT Injector Test Bench 450 X 450 X 350 1.5Kw  1050 R/Min 3phases
PT Injector Test Bench 450 X 450 X 350 1.5Kw  1050 R/Min 3phases
Product Details:
Place of Origin: CHINA
Brand Name: ADMTECK
Certification: CE
Model Number: PT-200G
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Polyboard
Delivery Time: TWO WEEKS
Payment Terms: T/T
Contact Now
Detailed Product Description
Highlight:

PT Injector Test Bench

,

450x450x350 Injector Test Bench

,

Injector 3phases Test Bench

PT-200G injector test stand is used to calibrate the CUMMINS N.K.L10 and M11 series injectors



Main Specifiions:

1. camshaft drive motor: 1.5Kw

2. camshaft speed: 1050 r/min

3. supply fuel pressure PI: 100PSI

4. clamping pressure PII: 78 PSI

5. metering range(strokes): 0-1000cc

6. type of belt 4x85x25

7. temperature of fuel: 38±2℃

8. fuel tank dimension: 450x450x350

9. power supply: 3phases, 50Hz, 380V AC

10. dimension: 1020x800x1470

11. weight: 450Kg

PT Injector Test Bench 450 X 450 X 350 1.5Kw  1050 R/Min 3phases 0PT Injector Test Bench 450 X 450 X 350 1.5Kw  1050 R/Min 3phases 1PT Injector Test Bench 450 X 450 X 350 1.5Kw  1050 R/Min 3phases 2
